TECHNICAL SPECIFICATIONS:
Condition: New
Type: High-frequency rectifier
Mains voltage: 1-phase 230V AC
Charging voltage: 12V / 24V
Charging current: 3–60A
Capacity of batteries charged (6-8h): 20-240Ah
Capacity of batteries charged (9-12h): 40-360Ah
Capacity of batteries charged: 201-499Ah (current 30-60A)
Battery types: AGM, WET (lead-acid), LiFePO4, GEL
Dimensions: 320 mm x 140 mm x 80 mm
Weight: 4 kg
Protection rating: IP31
Operating mode: Charger / Power supply
DESCRIPTION:
A high-quality high-frequency charger suitable for all types of batteries, including one specially adapted to work with Trojan AES AGM batteries in cleaning machines.
It allows for the programming of charging parameters (voltage, current and charging curves) and automatic start-up upon battery connection.
Equipped with an LCD display showing voltage, current, capacity (Ah) and battery charge status, as well as protection against short circuits, reverse polarity and overheating.
Designed for industrial applications; includes a power cable with a Schuko plug.
Key features:
• Programming via Program Shooter
• Automatic start-up upon battery connection
• LCD display: voltage, current, Ah, state of charge
• Protections: short circuit, reverse polarity, overheating
• Power cable with Schuko plug
• Compatible batteries: AGM, WET, GEL, LiFePO4, including AES AGM Trojan
• Charging voltage: 12V / 24V
• Charging current: 3–60A
• Dimensions: 320 x 140 x 80 mm
• Weight: 4 kg
• Protection rating: IP31
The charger is compatible with the following models:
Comac Abila 20B (fitted with AES AGM Trojan batteries)
NOTE:
Before purchasing, please ensure that the charger is compatible with your machine and batteries. If in doubt, please contact our technical advisor.
